260M-25-1K
Hadicová spojka | kužeľový závit
There is an option to record special requests on the order summary page
260M-25-1K
Hadicová spojka | kužeľový závit
| Product number | Prípoj | Vnútorný priemer hadice |
|---|
| Typ | Vnútorný priemer hadice | Prípoj G | L1 | i | S |
|---|---|---|---|---|---|
| 260M-2-M5 | 1,6...2 | M 5 | 12 | 4 | 8 |
| 260M-3-M5 | 2,7...3 | M 5 | 12 | 4 | 8 |
| 260M-10-1/4 | 9...10 | G 1/4" | 24,5 | 8 | 17 |
| 260M-14-1/4 | 12...13 | G 1/4" | 24,5 | 8 | 17 |
| 260M-14-3/8 | 12...13 | G 3/8" | 24,5 | 9 | 19 |
| 260M-14-1/2 | 12...13 | G 1/2" | 25 | 10 | 24 |
| 260M-14-1/2K | 12...13 | G 1/2" | 25 | 10 | 22 |
| 260M-16-1/2K | 16...17 | G 1/2" | 24,5 | 14 | 22 |
| 260M-20-1/2 | 18...19 | G 1/2" | 29,5 | 10 | 24 |
| 260M-20-3/4K | 18...19 | R 3/4" | 37 | 13,5 | 27 |
| 260M-25-3/4K | 23...24 | R 3/4" | 37 | 14,5 | 27 |
| 260M-25-1K | 23...24 | R 1" | 37,5 | 16 | 34 |
| Availability: | In stock |
|---|---|
| Materiál: | Poniklovaná meď |
| Materiál tesnenia: | Bez tesnenia |
| Menovitý tlak: | 0…50 bar |
| Pracovné médium: | Stlačený vzduch |
| Pracovný tlak: | 0…50 bar |
| Prevedenie: | Závitová |
| Prípoj: | R 1" |
| Teplotný rozsah: | -40°C…+120°C |
| Vnútorný priemer hadice: | 23…24 mm |
